PROCURAL PE78EI display cabinets for interior use

Characteristics

A system with a three-chamber design, intended for the construction of internal fire partitions.

Characteristics

• the ability to make full use of natural light and create a sense of space, whilst maintaining optimal fire resistance (EI60)
• no restrictions on the maximum width of the entire structure
• maximum width of a single glass pane: 1.76 m
• maximum height of a single glass pane: 3.52 m
• maximum area of a single glass pane: 5.68 m
• the joints between two glass panes are only 4 mm wide and are filled with fire-retardant intumescent material and non-combustible silicone
• the solution is covered by the current Fire Resistance Classification and National Technical Assessment


Technical specifications

EN AW-6060 aluminium
profiles in accordance with PN-EN 573-3, T66 temper in accordance with PN-EN 515

Frame
depth: 78 mm

Single-glazed units
with fire-resistant properties, in accordance with the National Technical Assessment, with a fire resistance rating of 26 or 31 mm

National Technical
Assessment ITB-KOT-2017/0351 – "Internal fire-resistant and/or smoke-proof doors, fire-resistant windows and a set of products for the construction of fire-resistant internal and external walls of the PROCURAL PE78EI system made of aluminium profiles with a thermal break"
ITB-KOT-2018/0529 - "Set of products for the construction of all-glass internal fire-resistant walls of the PROCURAL PE78EI system made of aluminium profiles with a thermal break"
