GSF KPR E | EW roller fire doors

The GSF KPR E I EW fire-rated roller shutter door is designed for use as a vertical movable partition to close off passages between fire separation zones in industrial facilities, storage rooms, public buildings, multi-family residential buildings and other structures. It can be installed both inside and outside the building.

Fire resistance class of E roller fire doors:

E15, E20, E30, E45, E60, E90, E120, E180

Fire resistance class of E roller fire doors:

EW15, EW20, EW30, EW45, EW60, EW90, EW120, EW180

Advantages:

• lightweight construction
• easy assembly
• large size
• aesthetic appearance
• CE Safety Certificate
• Declaration of Performance
• EPD Environmental Declaration

Construction of a roller fire door:

• flexible gate cover
• guide assembly
• winding shaft
• shaft housing
• ballast strip
• electric motor or fuse lock

The door curtain, made of fire-resistant fabric, is wound onto a winding shaft and held in the open position. The door is controlled by:

• electric drive – can be integrated with the SAP/SSP system
• fuse lock – in the event of a fire, at a temperature of approx. 74°C, the fuse lock is released and the curtain falls by gravity.

Additional options:

• painting of the guide assembly, housing and screws in any colour from the RAL palette
• smoke resistance in class Sa4, S200
• service category (number of operating cycles) up to C2
• wind resistance up to class 3
• installation on a layer of wool insulation (using spacer elements)
• installation on a steel structure
• stainless steel casing and guides
