GSF BP EI sliding fire doors

The GSF BP EI fire-rated sliding gate is designed for use as a horizontal movable partition to close off passages between fire separation zones in industrial facilities, storage rooms and public buildings. They can be installed both inside and outside the building. They effectively prevent the spread of fire, temperature and heat radiation. Thanks to the use of advanced fire protection technologies, the door is a reliable protective barrier that meets the highest safety standards.

The GSF BP EI gate is suspended in a running rail and held in the open position by an electromagnetic holder connected to the control unit. The gate closes by gravity, using a counterweight. In the event of a fire hazard, the control unit releases the magnet and the gate closes the passage between fire zones when it receives a signal from a smoke or heat detector or from the fire alarm system.

Fire resistance class of EI sliding fire doors:

EI30, EI60, EI90, EI120

Advantages:

• simple installation – all components are already matched during production
• high quality and aesthetics
• three colours as standard: RAL9010 – white, RAL7035 – light grey, RAL7016 – anthracite
• Hygiene Certificate
• CE Safety Certificate
• Declaration of Performance
• EPD Environmental Declaration

Construction of a sliding fire door:

• gate wing
• track assembly
• entry pocket
• ballast assembly
• wall closer

Additional options:

• painting of gates and covers in any colour from the RAL palette
• passage or emergency doors
• service category (number of operating cycles) up to C2
• installation on a steel structure
• option of manufacturing the gate from stainless steel
