Windows for the PF152EI ESG system
Characteristics
A three-chamber system designed for internal or external fire barriers.
Characteristics
- innovative glazing method with a single glazing bead – on the other side, the glass surface can form an almost single plane with the sash
- shorter production and installation time than with double-glazed products
- convenient glass installation using pressure sliders
- protection against detachment of the fire protection tape by installation in the rebate
- many variants of door leaf designs
- possibility of manufacturing large-size structures
- possibility of manufacturing smoke-proof structures
- possibility of combining with other EI30 and EI90 fire protection systems by using the same 78 mm profile depth
- possibility of connecting to EI120 fire protection systems by using adapter profiles
- possibility of manufacturing internal and external doors for exits and escape routes
- solution covered by the current Fire Resistance Classification, National Technical Assessment and Classification Report
Technical specifications
Aluminium sections
EN AW-6060 according to PN-EN 573-3, condition T66 according to PN-EN 515
Door frame depth
78 mm
Sash depth
78 mm
Single glazing
with fire-resistant properties, double glazing: PN - EN 1279-1, PN - EN 1279-5, opaque panels: according to National Technical Assessment, Fire Resistance Classification or Classification Reports 20 - 62 mm
Sound insulation
with single glazing 17 mm thick, with fire protection properties: according to the RA1 index - 35 dB, RA2 - 35 dB, RW - 37 dB
Smoke resistance
class Sa and S200 according to PN-EN 13501-2
National Technical Assessment
ITB-KOT-2017/0351 - "Internal fire-rated and/or smoke-proof internal doors, fire-rated windows and a set of products for constructing internal and external fire-rated walls using the PROCURAL PE78EI system with aluminium profiles with a thermal break"
Approvals and quality certificates Classification
reports for external doors, certified according to PN-EN 16034 and PN EN 14351-1+A2 standards
